Ficha técnica e características
Produto seminovo aprovado em todos os testes.
Produto Seminovo
Subtype: Gigabit Ethernet
Ports: 48 x 10/100/1000 (PoE+)
Power Over Ethernet (PoE)PoE+
PoE Budget800 Watt
PerformanceSwitching capacity: 176 Gbps
Stacking bandwidth: 480 Gbps
CapacityIPv4 routes: 24000
NetFlow entries: 48000
Switched virtual interfaces (SVIs): 1000
Jumbo Frame Support: 9198 bytes
Authentication Method: Kerberos, RADIUS, Secure Shell (SSH), TACACS+
RAM: 4 GB
Flash Memory: 2 GB
MAC Address Table Size: 32000 entries
Authentication Method: Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Power Over Ethernet (PoE): PoE+
Status Indicators: Port transmission speed, port duplex mode, system, status, PoE
Routing Protocol: RIP-1, RIP-2, EIGRP, RIPng
Jumbo Frame Support: 9198 bytes
PoE Budget: 800 W
POWER DEVICE
Power Provided: 1100 Watt
Nominal VoltageAC 120/230 V
Frequency Required50/60 Hz
Type: internal power supply
NETWORKING
MAC Address Table Size: 32000 entries
Subcategory: network hubs and switches
Subtype: Gigabit Ethernet
Form Factor: desktop, rack-mountable
Advanced Switching: Layer 3
Features: ARP support, Access Control List (ACL) support, Cisco StackPower technology, Cisco StackWise-480 technology, DHCP snooping, Dynamic ARP Inspection (DAI), Dynamic Trunking Protocol (DTP) support, Energy Efficient Ethernet, Flexible NetFlow (FNF), IGMP snooping, IPv4 support, IPv6 support, Link Aggregation Control Protocol (LACP), MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, PoE+, Port Aggregation Protocol (PAgP) support, Quality of Service (QoS), RADIUS support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid Spanning Tree Protocol (RSTP) support, Remote Switch Port Analyzer (RSPAN), STP Root Guard, Shaped Round Robin (SRR), Syslog support, Trivial File Transfer Protocol (TFTP) support, Uni-Directional Link Detection (UDLD), VLAN support, Virtual Route Forwarding-Lite (VRF-Lite), auto-negotiation, auto-uplink (auto MDI/MDI-X), layer 3 load balancing, trunking
Compliant StandardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Jumbo Frame Support: 9198 bytes
Ports Qty: 48
Manageable: Yes
Routing Protocol: EIGRP, RIP-1, RIP-2, RIPng
PoE Budget: 800 Watt
Remote Management Protocol: CLI, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, SSH, Telnet
Power Over Ethernet (PoE): PoE+
Power Redundancy Scheme: 1+1 (with optional power supply)
Max Supported Qty: 2
INTERFACE PROVIDED
Interface: Ethernet 10Base-T/100Base-TX/1000Base-T, RS-232, console
Qty1, 2, 48
Connector Type: RJ-45, mini-USB Type B
PoE Power: 30 Watt
Comments: PoE+, management
RAM
Installed Size: 4 GB
ENVIRONMENTAL PARAMETERS
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Min Operating Temperature: 23 °F
Max Operating Temperature: 113 °F
Humidity Range Operating: 10 - 95% (non-condensing)
DIMENSIONS & WEIGHT
Width: 17.5 in
Depth: 18.9 in
Height: 1.8 in
Weight: 17.64 lbs
